Deutz TCD 2015 V08 Engine ECU 4214432 Error Clear By HSlight II

Deutz TCD 2015 V08 Engine ECU 4214432 Error Clear By HSlight II (1)

This instruction show a guide on how to use HSlight II work with Serdia2000 to delete trouble code for Deutz TCD ECU 4214432 v08 engine 2015.



What you need?

Deutz HSlight II Diagnostic Kit with Serdia2000



Steps:

Connect HSlight II diagnostic kit on your Deutz machine,then run Serdia2000 software to do communication between Serdia2000 and engine.

Deutz TCD 2015 V08 Engine ECU 4214432 Error Clear By HSlight II (1)

Click “Error memory”–>”Error Memory 2” from menu bar

Deutz TCD 2015 V08 Engine ECU 4214432 Error Clear By HSlight II (2)

It will show you active error code as below picture

Click “Clear ECM”

Deutz TCD 2015 V08 Engine ECU 4214432 Error Clear By HSlight II (3)

Follow below guide to do it

Error memory 2 deleted!In order to update error memory,reset ECU (Ignition Off–>On) and then press OK.

Deutz TCD 2015 V08 Engine ECU 4214432 Error Clear By HSlight II (4)



After communication reconnection,click “Error memory”–>”Error Memory” from menu bar

Deutz TCD 2015 V08 Engine ECU 4214432 Error Clear By HSlight II (5)

Then just do same operation

Deutz TCD 2015 V08 Engine ECU 4214432 Error Clear By HSlight II (6) Deutz TCD 2015 V08 Engine ECU 4214432 Error Clear By HSlight II (7) Deutz TCD 2015 V08 Engine ECU 4214432 Error Clear By HSlight II (8)



Posted on by

Deutz EMR3 Engine Crankschaft Speed Sensor ECU NO Signal Solution

Deutz EMR3 engine control unit ArHt1.

Here is the instruction show you guide on how to solve Deutz EMR3 engine trouble code 77 / 190 / EngMCrS1 Crankschaft speed sensor: the ECU receives no signal or the signal is defective.

Deutz EMR3 engine control unit ArHt1.

Related Contents:

Deutz Serdia 4.0

Deutz DECOM





Error Codes

DEUTZ-Errorcode: 77

BlinkCode (short-long-short): 2 – 1 – 2

SPN: 190



Possible FMI:

12: Defective component

8: unusual frequency, pulse or period.

  1. Errormode not identifiable
  2. Errormode not identifiable



Error Detection

Error lamp shows permanent light. Entry in errormemory.



Possible Reason for Error

Speed signal from crankshaft defectiveiv or missing, transmitter defective, connection cable demaged, sensor wheel installed inaccurately



Take actions for error repair

Check cabling, check camschaft sensor and if necessary replace it, check configuration of sensor wheel, check connection cable and if necessary repair or replace it, check the position of sensor

wheel and if necessary correct it other error properties



System reaction:

Warning, power reduction via second topcurve



Behaviour error lamp: permanent light

Selfhealing: yes

Signal Priority: 4

Measurement @ errortime: 0

Posted on by

How to Solve Deutz EMR3 74 / 923 Engine Power Out Error?

This instruction show you guide on how to solve Deutz EMR3 Engine power out error 74/923 error.

Deutz EMR3 engine control unit ArHt1.

Error Description ENGINE POWER OUT

Output with PWM signal of the engine power: the current drain measured by ECU is out of the target range or the maximum permissible temperature of the ECU component to control the

output is exceeded.



Related Contents:

Deutz Serdia 4.0

Deutz DECOM





Error Codes

DEUTZ-Errorcode: 74

BlinkCode (short-long-short): 5 – 5 – 5

SPN: 923

Possible FMI:

3: Voltage to high or short circuit to +Ubatt

4: Voltage to low or short circuit to -Ubatt

5: current to low or broken wire

2: data stream is defective



Error Detection

Error lamp shows permanent light. Entry in error memory.



Possible reason for error

Engine Power output: cable break or short circuit, output defective, connection cable damaged



Take actions for error repair

Check cabling, sensor defect, check sensor and if necessary replace it, check connection cable and if necessary repair or replace it



Other Error Properties

System reaction: Warning, shutoff output

Behaviour error lamp: permanent light

Selfhealing: no

Signal Priority: 1

Measurement @ errortime: shut off value

Posted on by

How to Solve Deutz EMR3 55/110 Coolant Temperature Sensor Error

Deutz EMR3 engine control unit ArHt1.

Here is the instruction show you guide on how to solve Deutz EMR3 engine 55/110 coolant temperature sensor error.

Deutz EMR3 engine control unit ArHt1.

Error description ENG COOLANT TEMP

Coolant temperature sensor: the voltage of the sensor measured by ECU is out of the target range; the coolant temperature calculated by ECU is implausible compared with the oil temperature or the received value via CAN is defective



Related Contents:

Deutz Serdia 4.0

Deutz DECOM





Error codes

DEUTZ-Errorcode: 55

BlinkCode (short-long-short): 2 – 2 – 5

SPN: 110



Possible FMI:

3: Voltage to high or short circuit to +Ubatt

4: Voltage to low or short circuit to -Ubatt

2: data stream is defective

2: data stream is defective



Error Detection

Error lamp shows permanent light. Entry in error memory.



Possible reason for error

Cable break or short circuit, lamp defective, connection cable damaged



Take actions for error repair

Check cabling, sensor defect, check sensor and if necessary replace it, check connection cable and if necessary repair or replace it other error properties



System reaction: Warning, substitute value

Behaviour error lamp: permanent light

Selfhealing: yes

Signal Priority: 4

Measurement @ errortime: default value

Posted on by

How to Solve Deutz EMR3 SPN1323 Cylinder 1 Misfire

Deutz EMR3 engine control unit ArHt1.

This instruction show you guide on how to solve Deutz engine EMR3 SPN1323 error code 38 misfire at cylinder 1.



Error description MISFIRE CYL. 1

Misfire at cylinder 1: the number of the misfire detected by ECU  is out of the allowed limit value

Deutz EMR3 engine control unit ArHt1.



Related Contents:

Deutz Serdia 4.0

Deutz DECOM





Error codes

DEUTZ-Errorcode: 38

BlinkCode (short-long-short): 2 – 4 – 1

SPN: 1323



Possible FMI:

Defective component

Errormode not identifiable

Errormode not identifiable

Errormode not identifiable



Error detection

Error lamp shows permanent light. Entry in error memory.



Possible reason for error

Misfire detected (cylinder 1), magnet valve or injection pump defective, fuel system defective, motor engineering damaged



Take actions for error repair

Check magnetic valve or injection pump and if necessary replace them, check fuel system and if necessary repair it, check motor engineering and if necessary repair it other error properties



System reaction:

Behaviour error lamp: permanent light

Selfhealing: no

Signal Priority: 0

Measurement @ errortime: act

Posted on by

How to Solve Deutz EMR3 Charge Air Press 32 / 102 / BPSCD Error

This instruction show you guide on how to solve Deutz EMR3 Charge air press 32/102/BPSCD error.Charge air pressure sensor: the measured voltage of sensor by ECU is out of the target range; the calculated charge air pressure is implausible or the received value via CAN is defective.



Related Contents:

Deutz Serdia 4.0 Diagnostic Software

Deutz DECOM Interface Diagnostic Kit



Error codes

DEUTZ-Errorcode: 32

BlinkCode (short-long-short): 2 – 2 – 3

SPN: 102



Possible FMI:

3: Voltage to high or short circuit to +Ubatt

4: Voltage to low or short circuit to -Ubatt

2: data stream is defective

2: data stream is defective



Error Detection

Error lamp shows permanent light. Entry in error memory.



Possible reason for error

Cable break or short circuit, sensor defective, onnection cable  demaged



Take actions for error repair

Check cabling, if LDF6T sensor not working, check sensor and if

necessary replace it, check connection cable and if necessary repair or replace it

other error properties



System reaction: Warning, substitute value

Behaviour error lamp: permanent light

Self healing: yes

Signal Priority: 4

Measurement @ error time: default value

Posted on by

Deutz EMR3 Engine Description

With the start-up of the Deutz Tier lll engines the engine management system EMR3 will be used with the control units EDc16 and EDC7.

For the DCR (DEUTZ Common Rail System for TcD2012, TCD2013) the EDc16 is used as the standard control system, for the PLD system (pump-line-nozzle system for TCD2015) the EDC7. Both systems allow a precise control of the fuel injection depending on the engine operating parameters.



They contain functions which are necessary for achieving a high system security level and the required exhaust quality.



Related Contents:

Deutz SerDia 4.0

Deutz DECOM



Functional description EMR3

The control units EDC 16 / EDC 7 are compatible with the EMR2 with regards to the interface

functions. The following standard functions are provided:

ambient pressure-depending filling limit

monitoring and engine protection functions: fuel filter, fuel pre-pressure,

charge air temperature, rail pressure, oil pressure, coolant temperature, speed engine stop by switch



In addition to this the following optional functions are provided control of starter with start procedures (restart lock etc.)

speed control/limitation

Multiple State Switch 1 (up to 4 fixed speeds selectable)

Multiple State Switch 2 (up to 4 torque curves selectable)



extendable monitoring and engine protection functions: coolant level, air filter differential

pressure and two further temperatures for customer application (e.g. gear oil temperature)

extended test functions engine brake control override function (delay of engine shutdown)

automatic engine shutdown (engine protection) or only shutdown request (for special applications)



System elements EMR3

The EMR 3 system consists of at least these elements:

control unit

speed sensors for the crankshaft and the camshaft

rail pressure sensor, rail pressure control valve (MPROP)

temperature sensor(coolant)

combined charge air pressure and charge air temperature sensor

oil pressure sensor

ambient pressure sensor (integrated in the control unit)

speed setpoint transmitter, accelerator pedal

signal light for warning, diagnostics, error message etc.

diagnosis button

engine wire harness and vehicle wire harness

monitoring fuel pre-filter (water in fuel)

Posted on by

Deutz EMR3 SPN 523561 Trouble Code Solution

Deutz EMR3 engine control unit ArHt1.

Error description INJECT. PERIOD ZYL.1
Begin of injection of cylinder 1: the ECU can not identify the magnet valve or the injection pump with the measured value of current drain at the begin of the injection

Deutz EMR3 engine control unit ArHt1.

24 / 523561 / BIPCyl1

Preparations:

2023 Deutz Serdia2010

Deutz DECOM Diagnostic Kit





Error codes
DEUTZ-Errorcode: 24
BlinkCode (short-long-short): 5 – 3 – 1
SPN: 523561

possible FMI:
2: data stream is defective
2: data stream is defective
2: data stream is defective
2: data stream is defective

Errordetection
Errorlamp shows permanent light. Entry in errormemory.

Possible reason for error
Value outside target range or missing (cylinder 1), magnet valve or injection pump defective
Take actions for error repair
Check magnetic valve or injection pump and if necessary change them other error properties
System reaction: No function at the moment/ Allocation check cylinder!
Behaviour error lamp: permanent light
Selfhealing: yes
Signal Priority: 3

Posted on by

Deutz EMR3 Engine Trouble Code 22 / 168 / BattCD Solution

Here is the instruction show you guide on how to repair trouble code 22 / 168 / BattCD for Deutz EMR3 engine.

Deutz EMR3 engine control unit ArHt1.

Preparations:

2023 Deutz Serdia2010

Deutz DECOM Diagnostic Kit




Error description BATTERY VOLTAGE
Battery voltage: the voltage measured by ECU is out of the target range

Error codes
DEUTZ-Error code: 22
Blink Code (short-long-short): 3 – 1 – 8
SPN: 168
possible FMI:
0: data valid, but above normal working area
1: data valid, but below normal working area
12. Errormode not identifiable
12. Errormode not identifiable

Error detection
Error lamp shows permanent light. Entry in error memory.

Possible reason for error
Voltage below target range, battery defective, too high power supply voltage, too high contact resistance, wiring damaged,energie system overloaded, parametering inaccurate, ECU defective

Take actions for error repair
Check LIMA?, ECU, cabling, contact resistance, safety fuses, too high load in energy system, check battery and if necessary replace it, check battery pole and if necessary clean it, check connection cable and if necessary repair or replace it, check volta



other error properties

System reaction: Warning, substitute value, dependent upon supply voltage (12V, 24V)
Behaviour error lamp: permanent light
Selfhealing: yes
Signal Priority: 3

Posted on by

DEUTZ EMR3 Engine Control Unit 17/729/ArHt1 Trouble Repair

Here is the instruction show you guide on how to repair Deutz EMR3 engine control unit trouble code 17/729/ArHt1.

Deutz EMR3 engine control unit ArHt1.

Preparations:

2023 Deutz Serdia2010

Deutz DECOM Diagnostic Kit





17 / 729 / ArHt1
Error description AIR HEATER RELAY
Air heater relay: the current drain measured by ECU is out of the target range

Error codes
DEUTZ-Errorcode: 17
BlinkCode (short-long-short): 2 – 6 – 3
SPN: 729

possible FMI:
3: Voltage to high or short circuit to +Ubatt
4: Voltage to low or short circuit to -Ubatt
5: current to low or broken wire
12. Errormode not identifiable

Errordetection
Errorlamp shows permanent light. Entry in errormemory.

Possible reason for error
Cable break or short circuit at EDC output, relay defective,
connection cable demaged

Take actions for error repair
Check cabling, if sensor not working, check relay and if necessary replace it, check connection cable and if necessary repair or replace it

other error properties
System reaction: Warning, shutoff output
Behaviour error lamp: permanent light
Selfhealing: yes
Signal Priority: 2
