Genuine Kubota DST-i Diagnostic Adapter for Kubota Takeuchi Machine

(1 customer review)



Kubota DENSO DST-i Diagnostic Kit provides mechanics with access to controllers that are normally only used by auto dealerships working with this special equipment. This feature of the equipment is often the main reason why car services, construction companies and farms decide to buy this diagnostic adapter.


Kubota DST-i diagnostic adapter support variety of DENSO ECMS.It support many OEM software to do diagnostics function and programming.It support Kubota and HINO engine diagnostic and programming.

Note:This product need re-order,my team need about 7 days to prepare it.


Kubota DST-i Diagnostic Adapter Features:

Genuine made

with Kubota DiagMaster software

Run faster than old version

Free DHL shipping


Kubota DST-i Diagnostic Adapter Work with Diagmaster Software:


Kubota DST-i Diagnostic Adapter Functions:



Data monitor




Kubota DST-i Diagnostic Adapter Specification

Item Specifications
CPU 32-bit RISC microcomputer
Memory Built-in Flash ROM 16 MB
LCD Size 2.7 inch TFT color LCD
Resolution QVGA (320 x 240 dots)
Display color Max. 260000 colors
Input device Operation keys 6 keys
External interface *2 USB USB 2.0 x 1
Bluetooth *1 Bluetooth 2.0
SD memory card Slot x 1 (supporting SD and SDHC memory cards)
DC jack JEITA4 standard type
Vehicle communication Dedicated connector (D-sub 25 pin) x 1
ISO9141, CAN
Main unit power
supply voltage
Vehicle power supply DC 6.5 to 32 V (Datalink cable)
USB power (BUS power) DC 4.75 to 5.25 V *3
Power consumption Normally 1.5 W (12 VDC), Max. 2.5 W (12 VDC)
Operating temperature
[Storage temperature]
0 to 50°C [-10 to 60°C]
Operating humidity 35 to 85% (No condensation)
Dimensions 135 mm (W) x 70 mm (H) x 35 mm (D)
Weight Model without Bluetooth Approx. 225 g
Model with Bluetooth Approx. 230 g


Kubota DST-i Diagnostic Adapter Packages:

1 x DST-I Kubota main unit

1 x USB cable

1 x OBD DLC Cable

1 x 4-PIN Kubota cable

1 x SD memory card

1 x High quality box

1 review for Genuine Kubota DST-i Diagnostic Adapter for Kubota Takeuchi Machine

  1. lurenzipo

    their team is professional on it,they help me to install Diagmaster software and setup connection
